Technical features
Medium:
Compressed air
Operating pressure:
Vacuum -18 bar (261 psi) maximum
Vacuum
-750 mm of Hg i.e 98%
Ambient/Media temperature:
-20 … +80°C (-4 … +176°F)
Tube sizes:
4, 5, 6, 8, 10, 12, 14 mm O/D
Tubing types:
PA 11 or 12 PU´R and other plasticised or unplasticised tubing which conforms to the tolerances specified in BS 5409, Part 1, 1976, light and normal duty, DIN 73378, DIN 74234, NFE 49-100
Materials:
Nickel plated brass body
Nickel plated brass for collet
VMQ free NBR
O-ring (FMP optional)
Plastic sealling washer (parallel threads)
Non – PTFE thread sealant (taper threads)
