Technical Specifications
| Availability | Global |
| Pretravel (PT) | 51 mm [2 in] |
| Actuator | Wobble – Coil Spring |
| Circuitry | 1NC 1NO SPDT Snap Action, Double Break |
| Housing Material | Zinc Die-Cast |
| Sealing | NEMA 1, 3, 4, 4X, 6, 6P, 12, 13 |
| Series Name | HDLS |
| Operating Temperature | -12 °C to 93 °C [10 °F to 200 °F] |
| Agency Approvals and Standards | UL, CE, CSA, CCC. EN60947-1, EN60947-5-1 |
| UNSPSC Commodity | 39122213 Limit Switches |
| Operating Force (OF) | 1,95 N [7 oz] max. |
| Product Type | MICRO SWITCH Heavy-Duty Limit Switches |
| Termination Type | 0.5 in – 14NPT Conduit |
| Supply Voltage | 600 Vac and 250 Vdc max. |
| Ampere Rating | 10 A (Thermal) |
| Housing Type | HDLS Plug-in |
| UL File # | E37138 |
| Comment | 5.5 in Coil Spring Actuator |
| UNSPSC Code | 39122213 |
| Sealed | Industrial |
