Technical Specifications
| Availability | Global |
| Pretravel (PT) | 15° max. |
| Differential Travel (DT) | 7° max. |
| Actuator | Side Rotary |
| Circuitry | 2NC 2NO DPDT Snap Action, Double-Break |
| Housing Material | Zinc Die-Cast |
| Sealing | NEMA 1, 3, 4, 4X, 6, 6P, 12, 13 |
| Lever Type | Lever Not Included – Reference Lever Required Accessory |
| UL File # | E37138 |
| Agency Approvals and Standards | UL, CE, CSA, CCC. EN60947-1, EN60947-5-1 |
| UNSPSC Commodity | 39122213 Limit Switches |
| Operating Force (OF) | 0,45 N m [4 in lb] max. |
| Overtravel (OT) | 60° min. |
| Product Type | MICRO SWITCH Heavy-Duty Limit Switches |
| Termination Type | 0.75 in – 14NPT Conduit |
| Supply Voltage | 600 Vac and 250 Vdc max. |
| Ampere Rating | 10 A (Thermal) |
| Housing Type | HDLS Plug-in |
| Series Name | HDLS |
| Operating Temperature | -12 °C to 121 °C [10 °F to 250 °F] |
| UNSPSC Code | 39122213 |
| Sealed | Industrial |
