Actuator Type Plunger
Pole and Throw Configuration SPDT
Normal State Configuration NO/NC
IP Rating IP67
Maximum Current 6 A
Housing Material Die Cast Zinc
Maximum ac Voltage 600V
Maximum dc Voltage 250V
Series GLA
Contact Type Snap Action
Terminal Type PG13.5 Connector
Length 145.8mm
Width 42mm
Minimum Operating Temperature -25°C
Dimensions 145.8 x 42 x 42 mm
Depth 42mm
Mechanical Life Minimum 15000000 cycles
Maximum Operating Temperature +85°C
Alkuperämaa GB
