Technical Specifications
| Approvals | Div 1 & 2, Class I Groups B, C, & D; Div 1 & 2, Class II Groups E, F, & G; II 2 G Ex d IIC T6 Gb; 1 Ex d IIC T6 Gb; II 2 D Ex tb IIIC T85C Db |
| Series Name | BX Switches |
| Pretravel (PT) | 15° max. |
| Overtravel (OT) | 60° min. |
| Actuator | Side Rotary |
| Lever Type | 1.5 in Fixed Length Lever with front mounted Nylon Roller (.75 in dia. x .25 in wide) |
| Ampere Rating | 10 A (Thermal) |
| Termination Type | 20 mm Conduit |
| Sealing | IP67; NEMA 1, 3, 4, 6, 13 |
| Comment | Lever Included |
| UNSPSC Commodity | 39122213 Limit Switch |
| Agency Approvals and Standards | UL, CSA, ATEX (CE), IEC Ex, INMETRO, KOSHA, NEPSI, EAC (Gost-R) |
| Availability | Global |
| Differential Travel (DT) | 5° max. |
| Product Type | MICRO SWITCH Weather-Sealed, Explosion-Proof Limit Switches/European and Global Approvals |
| Supply Voltage | 600 Vac and 250 Vdc max. |
| Circuitry | 1NC 1NO SPDT Snap Action, Double-Break |
| Housing Material | Aluminum |
| Housing Type | BX Non Plug-in |
| Operating Temperature | -40°C to 70°C [-40°F to 158°F] |
| UNSPSC Code | 39122213 |
| Sealed | Explosion-proof |
